    CD15NMT-mini Navy Drones 20km Mapping Inspection 1.4G 0.3W Power Uav Video Transmitter

    Ask Lasest Price
    Brand Name : SUNTOR
    Model Number : CD15NMT-mini
    Certification : RoHS,FCC,SGS, CE
    Price : Negotiation
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 1000 set/ month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    CD15NMT-mini Navy Drones 20km Mapping Inspection 1.4G 0.3W Power Uav Video Transmitter

    Product Key Features of Drone Video Transmitter:


    Model:CD15NMT-mini
    Range:15km
    Weight:Tx 110g Rx 110g
    Dimension:88x55x17mm
    Video&Data:IP Ethernet x1 TTL x1
    TX Power:300mW(25dBm)
    Frequency:1.4GHz/800MHz/2.4GHz
    Rate:3-8Mbps, Max 30Mbps
    Latency: ≤50-70ms
    Weight:Tx 110g Rx 110g
    Consumption:TX 5W RX 5W
    Product Application of Drone Video Transmitter:
    Energy Oil&Gas/Precision Agriculture/Mapping
    Logistic Delivery/ Defense
    Aerial Surveys and Inspections/Geological Inspection

    Suntor CD15NMT-mini transmitter in real time video transmission for UAV system, mostly in drones mapping, oil gas papeline powerline inspection application

    Parameter

    Model: CD15NMT-mini
    Frequency800MHz 2.4G 1.4GHzAdjustable
    RF Transmitting Power300mW
    Frequency Bandwidth3MHz/5MHz/10MHz/20MHzAdjustable
    Antennasmall ruber MIMO Omni Antenna
    Adjustment mode of bit rateSoftware adjustment
    EncryptedAES 128
    Transmission ModePTP PTMP
    Start-up time< 30s
    Transmission RangeAir to ground 15-20km
    System Latency50-70ms
    Two-way function

    Integrate multiple radio links into one to transmit and receive.

    Support SBUS/Mavlink/TTL communication module

    Optional
    Transmitting Rate100Mbps
    ModulationOFDMDC9~18V Optional
    Module ConsumptionTX:5W RX:5WMaximum
    Temperature

    Operating temperature: -25 - 60°C

    Storage temperature: -30 - 70°C

    Indicator Light

    RJ45 input/output indicator light

    Transmitting and receiving indicator light

    Transmitting and receiving indicator light

    Power light

    Appearance DesignCNC technology/ double aluminum alloy shell with waterproof design
    Size88×55x17mm
    Net WeightTx:110g Rx: 110g

    Components List:


    1.Transmitter x 1pcs
    2.Receiver x 1pcs
    3.Antenna x 4pcs
    4.Feed Antenna Cable x 4pcs
    5.Ethernet Cable x 2pcs
    6.Power Cable x 2pcs

    Warranty:


    Products are warranted for 1 year from the date of package signed.
