Introduction

ST9601MS is a new robust Ethernet wireless transceiver radio from SUNTOR, specially designed for N-LOS (Non line of sight) wireless IP MESH communication.It provides complete bi-directional video data IP networks transmission in complex environment, work as PTP communication and PTMP self-organized networking, each mesh group can access up to 42 nodes. Since its TDD modulation with narrow band technology that able to extend the cover range and better diffraction even in moving conditions.

As its very small size, lightweight and bridge capacities, which is ideal for motion surveillance with high quality image and emergency communication. Widely apply in applications like law enforcement, public security and protection, , , fire control, emergency areas etc.

ST9601MS Key Features

• SUNTOR’s patented Mesh networking software, enabling the network
• to quickly adapt to rapidly-deployed and quickly- or constantly-moving
• network elements
• Multiple transceiver configurations for high levels of network reliability,
• redundancy and diversity, and fewer problems due to interference,
• congestion, and equipment outages
• Multiple radio frequencies – 300-900 MHz, 2.4 GHz, 1.4GHz as well as
• , licensed, public service, and other proprietary radio frequencies
• Multiple antenna-port configurations with 2x2 MIMO (multiple-input,
• multiple-output), substantially increasing the capacity of transceivers
• Support for several strong cryptographic options used for data and
• MAC-address encryption and per-hop, per-packet authentication
• Rugged and environmentally sealed enclosures
• High bandwidth for data, voice, and video applications
• Scalability to 42 high-bandwidth nodes
• Integrated Wi-Fi Access Point service for compatibility with millions of
• commercial off-the-shelf (COTS) client devices such as laptops, tablets,
• smart phones, IP cameras, sensors, and other IP devices
• Self-configuring operation for fast and easy deployments
• Reliable and fast off-loading to Ethernet via multiple, simultaneous
• bridge-mode links through the Automatic Protocol Tunneling (APT)
• feature
• Mesh Clustering to designate per-BreadCrumb sub-meshes that will only
• mesh with a user-specified series of nodes, useful applications include:
• Enabling two ST9601MS to operate in a point-to-point (PTP)
• capacity on the same channel as other mesh nodes, eliminating
• the need to purchase a third-party PTP link for backhaul
• Isolating one or more groups of ST9601MS to mesh with
• each other and not with other nodes outside the user-defined
• mesh cluster
