    PB33 Other Drone Security System COFDM IP MESH Radio Ground Control Station UGV/UAV For Safes

    Ask Lasest Price
    Brand Name : SUNTOR
    Model Number : PB33
    Certification : FCC, CE, RoHS
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 1000 set/ month
    Delivery Time : 7-15 days
    Price : Negotiation
    • Product Details
    • Company Profile

    PB33 Other Drone Security System COFDM IP MESH Radio Ground Control Station UGV/UAV For Safes

    PB33 Portable Command & Dispatch Platform Box Spec...


    Introduction


    PB33 is a wireless IP MESH central station, specially designed for outdoor applications such as urban coverage, drone video surveillance, and mission deployment.
    PB33 COFDM IP MESH integrated with tablet for wireless mesh network system operation and video surveillance and MESH network topology.

    Equipment Characteristic:


    1. Self-developed COFDM waveform, efficient channel coding, and multi-hop ad hoc networking protocols.
    2. Strong anti-interference ability.
    3. Forming a centerless wireless broadband network efficiently and quickly.
    4. Integrated with tablet PC, battery V lock, GPS, WIFI, 4G.
    5. Provide IP interface, which can realize interconnection with other IP devices.
    6. Built-in Wi-Fi/GPS/4G (Mobile/Unicom) module can be customized.
    7. Customized development can be provided according to customer requirements.

    Host characteristics
    Operating SystemWIN10/64bit
    CPUIntel I7 processor
    Display Screen17 inch HD bright screen
    Memory16G
    Storage Mode240G solid state drive
    Mode of operationEmbedded mouse and keyboard
    Transmission Characteristic
    Frequency Rang1438MHz(200MHz-1.5G customizable
    Channel Bandwidth5M/10M/20M (adjustable
    Transmitted PowerMax 33dBm
    Constellation Modulation(BPSK/QPSK/16-QAM (Adaptive))
    Forward error correcting code1/2, 2/3, 3/4, 5/6 Optional
    Digital SensitivityThe highest -93dBm@5MHz
    Transmission RatePeak rates are up to 70Mbps
    Networking CapabilityThe number of chain hops in an AD hoc network is more than 9. The number of nodes in an AD hoc network is not less than 32
    Data Characteristics
    Rf InterfaceN*2,SMA*1
    Video Display17 inch HD bright screen
    Cable InterfaceRJ45 Waterproof port *2
    Intercom Interface6-core navigational plug
    Data Interface3-core navigational plug (spare)
    Power Interface2-core navigational plug
    4G Functionall-netcom
    Signal LightFive signal lights
    Power switchFlip the self-locking switch
    Encryption ModeAES 256
    Electrical Characteristics
    Operating VoltageDC 14.8V
    Working Current≤ 7A
    Power ConsumptionThe average power consumption of the machine is 60W
    Battery Capacity10Ah
    Physical Characteristics
    Operating Temperature20~+55℃
    Storage Temperature-50℃~ +70℃
    Overall Dimension52.5*43.7*21.3cm
    Equipment Weight14.8kg (including battery)
