5W long distance HD SDI Manpack NLOS COFDM transmitter for
monitoring
ST6200DB-HD manpack HD wireless video transmission equipment is new
generation of real-time broadcast-quality high-resolution image
transmission system. It adopts the current leading COFDM modulation
technology, has the strong anti-jamming capability,overcomes the
reflection and cover caused by transmission multipath simulation
technique and conventional modulation techniques, to realize
high-speed photography and real-time transmit high quality image in
NLOS or complicated working environment.
Features:
Picture quality reach to Full HD via H.264 encode & decode, of
course the picture quality downward compatibility to 1080I, 720P or
480P. Support digital interface and analog interface, like HD-SDI &
High Definition Multimedia Interface and simulation port CVBS. The
advantage of the production include high resolution & contrast
ratio, good color performance.
Modulation | Working frequency | 300MHz～4.4GHz |
| Output power | 1～5W LCD adjust |
| Modulation | COFDM |
| Channel bandwidth | 2/2.5/4/8MHz |
| Encryption mode | manual operation AES double encryption |
| System | Standard | H.264 standard |
| Code stream | 2Mbps～12Mbps |
| Range | 1km(NLOS) 10km(LOS) |
| Usage mode | Manpack |
| Audio and video | Compression format | H.264 |
| AV input | HD-SDI or High Definition Multimedia Interface,CVBS(optional) |
| Audio input | BNC female port, HD-SDI or High Definition Multimedia Interface
standard interface |
| Image resolution | HD1080P(1920*1080), compatibility 1080I,720P,480P and standard resolution |
| Image frame rate | HD1080P/60fps, HD1080I/50fps |
| Video input physical interface | BNC female port, High Definition Multimedia Interface standard
interface |
| Audio input physical interface | BNC female port, High Definition Multimedia Interface standard
interface |
| Others | Power supply | special battery DC14.4V |
| LCD display | Display Work Instructions and the Parameters |
| Size | 200×125×50 mm (L×W×H) |
| Weight | 1.5kg |
Application:
This product has wide application, such as Public security, Fire
control, traffic, Civil defense emergency, City
management,Environment monitoring, Flood control,Electricity
rescue,Railway rescue,Maritime law enforcement,Maritime
surveillance inspections,Customs and Border Protection,Pier
monitoring,Forest Fire,Oilfield theft, reconnaissance,living
broadcast, and so on. It is suitable for urban area, seaborne,
mountainous region and other complex environment high quality image
mobile transmission.
